Features:
- Retained bar nuts
- Slimmed-down design
- LowVib
- Adjustable oil pump
- Magnesium crankcase
- AutoTune
- X-Torq
- Excellent cooling capacity for a longer engine life
- Felling sight to last a lifetime
- Air Injection
- Visible fuel level
- Snap-lock cylinder cover
- Side-mounted chain tensioner
- Three-piece crankshaft
- Retained starter screws
- Flip-up tank caps
Technical Specification:
- Power output – 3.0 kW
- Cylinder displacement – 50.1 cm³
- Maximum power speed – 10200 rpm
- Idling speed – 2800 rpm
- Torque, max. – 3.15 Nm
- Torque, max. at rpm – 7800 rpm
- Clutch engagement speed (±120) – 3900 rpm
- Fuel consumption – 432 g/kWh
- Fuel consumption – 1.3 kg/h
- Spark plug – NGK CMR6H
- Electrode gap – 0.5 mm
- Ignition module air gap – 0.3 mm
- Oil pump type – Adjustable flow, no flow at idle
- Exhaust emissions (CO2 EU V) – 813 g/kWh
- Recommended bar length, max – 20 in
- Recommended bar length, min – 13 in
- Chain speed at 133% of maximum engine power speed – 26.1 m/s
- Weight (excl. cutting equipment) – 5.3 kg
- Oil tank volume – 0.32 l
- Oil pump type – Adjustable flow, no flow at idle
- Sound power level, guaranteed (LWA) – 117 dB(A)
- Sound power level, measured – 115 dB(A)
- Sound pressure level at operators ear – 107 dB(A)
- Equivalent vibration level (ahv, eq) front handle – 3.3 m/s²
- Equivalent vibration level (ahv, eq) rear handle – 4.9 m/s²
