Features:
- Air Injection:Â Centrifugal air cleaning system for reduced wear and longer operating time between filter cleanings.
- Side-mounted chain tensioner:Â Side-mounted chain tensioner makes chain adjustment quick and easy.
- X-Torq: Deliver lower fuel consumption and reduced exhaust emission levels in accordance with the world´s most stringent environmental regulations.
- LowVib:Â Effective anti-vibration dampeners absorb vibration, sparing the user’s arms and hands.
- Adjustable oil pump
- Quick-release air filter
- Felling marks
- Combined choke/stop control
- Three-piece crankshaft
- Smart Start
- Better grip
- Inertia chain brake
- Fuel pump
Technical Specification:
- Power output –Â 2.6 kW
- Cylinder displacement – 55.5 cm³
- Maximum power speed –Â 9000 rpm
- Max engine/motor RPM –Â 13300 rpm
- Idling speed –Â 2700 rpm
- Torque, max. –Â 3.2 Nm
- Torque, max. at rpm –Â 6600 rpm
- Clutch engagement speed (±120) – 3800 rpm
- Fuel consumption –Â 407 g/kWh
- Fuel consumption –Â 1.1 kg/h
- Spark plug –Â Champion RCJ7Y, NGK BPMR7A
- Electrode gap –Â 0.5 mm
- Ignition module air gap –Â 0.3 mm
- Oil pump type –Â Automatic
- Oil pump capacity Max –Â 17 ml/min
- Oil pump capacity Min –Â 6 ml/min
- Exhaust emissions (CO2 EU V) –Â 893 g/kWh[1]
- Recommended bar length, max –Â 24 in
- Recommended bar length, min –Â 13 in
- Weight (excl. cutting equipment) –Â 6 kg
- Oil tank volume –Â 0.32 l
- Oil pump type –Â Automatic
- Oil pump capacity Max –Â 17 ml/min
- Oil pump capacity Min –Â 6 ml/min
- Sound power level, guaranteed (LWA) –Â 114 dB(A)
- Sound power level, measured –Â 112 dB(A)
- Sound pressure level at operators ear –Â 104 dB(A)
- Equivalent vibration level (ahv, eq) front handle – 3.8 m/s²
- Equivalent vibration level (ahv, eq) rear handle – 6.9 m/s²
